Multi-coil Wave Springs are made from flat-rolled spring wire that is coiled to a helical shape and the coils are at the same time given a sinus shaped wave form. The force-deflection relation is created by flattening out the wave form when the spring is compressed. The function is hence like a helically shaped leaf spring.
A wave spring suits perfectly in applications where a small installed length is required. For small strokes, the length of a multi-coil wave springs is lower than for conventional helical compression springs. For some requirements, this can reduce installed length by up to 50%.
We have a standard stock of wave springs that satisfy the majority of requirements. However, if you need a customized spring with specific dimensions, material etc. we are ready to assist you in designing the most optimal spring solution.
Dimensions
Outer spring diameter 7-250 mm
Special versions and special dimensions are available after individual consultation.
Our Lesjöfors sales contacts co-ordinate all your contacts within our organization and thereby rationalize your purchase process.
In spring steel, stainless steel or super alloys depending on your requirements
